Introduction of powder pneumatic conveying system
Pneumatic conveying of powder materials, also known as air conveying, is to use the energy of air flow to transport powder or granular materials in the direction of air flow in the closed pipeline, which is a specific application of fluidization technology. Powder pneumatic conveying system is a set of systems engineering, composed of a large number of accessories, usually including unpacking, feeding, storage, unloading, grinding, screening, metal detection, conveying and metering equipment.
Flow chart of environment-friendly building materials pneumatic conveying system in Dongguan
Introduction of powder conveying equipment
Vacuum conveying equipment is an important part of powder conveying equipment, it is the use of fully closed conveying equipment system to complete the transport of bulk materials (powder, particles), which completely eliminates the environmental pollution caused by material leakage and the harm to the operator's body, as well as the pollution of the surrounding environment for the material, is the development direction of powder conveying equipment in recent years. Vacuum feeder negative pressure source has many forms, such as: vacuum generator, vacuum pump, Roots fan and so on. The advantages of the vacuum generator are small size, light weight, easy to install, can be applied in the clean workshop it uses jet technology, so that the vacuum generator under the action of compressed air to produce high vacuum to achieve material conveying equipment.
Advantages of powder conveying equipment
Safety: no electrical energy, mechanical energy, only through the compressed air can control and run the entire system;
Simple: automatic control, set the suction and discharge time at will within 0~30 seconds, simple and convenient operation;
Health: meet GMP standards, meet CIP requirements;
Light: small size, light weight, simple and fast installation;
Quiet: no vibration, low noise
Design and installation of powder pneumatic conveying system
Wijay has professional project planning engineers to provide customers with technical advice, tailored to customer needs, to provide customers with solutions. Participated in customer projects from the beginning, from material unpacking and feeding, warehousing, production line logistics transportation, automatic mixing, host and back-end equipment to packaging of the whole line planning, plant layout, water and electrical road design, steel frame platform, dust removal system, waste gas treatment system and other industrial process planning. Optimize the site layout scheme, with the concept of safety, efficiency and environmental protection combined with professional skills to provide customers with supporting services.
Wijay Automation has been focusing on powder/fluid handling systems for more than 10 years, with 1000+ successful cases. We have successively designed and implemented powder and fluid raw material automation solutions for international first-class enterprises such as Nestle Group, Fortis Group, Jiashili Group, Hamazaki Group, BYD and petrochina. Adhering to the concept of value creation and strategic cooperation, Wijay has accumulated rich experience and good reputation in the three major fields of food and beverage, plastic chemical and environmental protection new materials, and won the trust of many Fortune 500 companies. Can provide pre-sales services are: whole plant planning, raw material testing, system program flow chart, system program layout, pneumatic conveying ISO diagram, system PPT presentation, system utility, profitability, equipment quotation.
